EEG and Mapping System Eeg Machine

Description

Dimension: 186 mm(L)×135 mm(W)×89.2 mm(H) Weight: 550g Operational environment: Temperature: +5℃~+40℃ Relative humidity: 25%~95% (no condensation) Atmospheric pressure: 700hPa~1060hPa Power supply: USB 5V DC Storage environment: Temperature:-20℃~+55℃ Relative humidity: ≤90% Atmospheric pressure: 700hPa~1060hPa Speed of sampling: 200 Hz/sec. Precision of sampling: 12 bit Input impedance: ≥10MΩ Patient leak current: < 10uA Level of noise: ≤5uV Vp-p CMRR: ≥90dB Magnifying multiple: 10 000 Filtering constant: all digital and free enactment Speed of displaying(paper speed): 5, 10, 15, 30, 60, 120 mm/s Displaying gain: 1,2,5,10,12,15,20 mm/50uv Speed of review: 1, 2, 3, 10, 20, 40, 60 50Hz interference suppression ratio: ≥30dB Details Images
